Model: NST-NVR7516P-4K1
SKU: 24-14-0008
In Stock
In Stock
Add to Wishlist
Add to Wishlist
Add to Wishlist
Add to Wishlist
1 Working Day Delivery ACS
Speedy and reliable parcel delivery!
Other people want this. 2 people have this in their carts right now.

Download PDF

Hard Disk is not included*


16 Channel 8MP 4K UHD H.265 Embedded Plug and Play PoE NVR With 16 Port PoE Switch DC48V Output


16 Channel 8MP H.265 NVR
With 16 Port PoE Switch DC48V OutpuT
Model No. NST-NVR7516P-4K1
System Main processor NT
Operating system Embedded LINUX operating system
System resource Simultaneous multi-channel real-time recording, playback, network operation, USB backup
Interface Operation interface 16-bit true color graphic menu operation interface, support mouse operation
Display screen 1/2/4/6/8/9/16
Video Video input (IP) 16*8MP/16*4K
Video standards PAL(625TVL,50f/s);NTSC(525TVL,60f/s)
Video compression H.265/H.264
Display quality Max:4K
Playback quality 4K/5M/4M/3M/1080P
Decode 4K(1)/5M(1+1)/4M(2+1)/3M(2+2)/1080P(4+1)
human shape / Face Depend on camera
Audio Audio compression G711A
intercom support
Record and playback Record mode Manual>Alarm>Dynamic Detection>Timing
Local playback 4K(1)/5M(1+1)/4M(2+1)/3M(2+2)/1080P(4+1)
Search mode Search by Time/Calendar/Event/Channel/Face
Storage and back up Record Storage HDD 、 network
Backup mode Network backup, USB hard disk, USB burner, SATA burner
Interface Video output 1ch HDMI HD Output ,1CH VGA Output
Audio I/O 1/ 1(3.5mm)
Alarm I/O 0/0
Network interface 1*SFP Port, 2* 100M/1000M Adaptive Ethernet port,16 POE Output ports
USB interface 2*USB2.0 port
Hard disk 1*SATA (Up to 14TB for each disk)
other PTZ control Control PTZ device by network
ONVIF Available
Power supply DC 48V /5 A
Power Consumption <10W(Without HDD)
Work environment Temperature:0℃- + 55℃ , Humidity:10% - 90%RH , Atm:86kpa - 106kp
Dimension L440*W320*H45MM
Weight 3.2KG


Support Face Detection

Support VGA, HDMI full HD output simultaneously;

Support ONVIF; access third party;

Support Web, CMS, center platform management software XMEYE, provide SDK development;

Support multiple cloud technology, network penetration, alarm information pushed to your phone and other functions;

Support various mobile monitoring (iPhone, Android);

Remote Access, With DNS (ARSP),easy to monitor remotely.
