GJFJV-1B6A2
|
No. of cable
|
1
|
|||
|
Tight lines
|
Material
|
PVC/LSZH
|
||
|
Thickness（±0.03）mm
|
0.32
|
|||
|
Diameter（±0.06）mm
|
0.9
|
|||
|
Colour
|
White
|
|||
|
Strength Member
|
Material
|
Aramid Yarn
|
||
|
Outer Sheath
|
Material
|
PVC/LSZH
|
||
|
Thickness（±0.05）mm
|
0.35
|
0.45
|
||
|
Cable Diameter（±0.2）mm
|
2.0
|
3.0
|
||
|
Cable Wetght（±2）kg/km
|
5
|
7
|
||
|
Allowable Tensile Strength
|
Short Term
|
N
|
150
|
|
|
Long Term
|
80
|
|||
|
Allowable Crush Resistance
|
Short Term
|
N/100mm
|
500
|
|
|
Long Term
|
100
|
|||
|
Min. bending radius
|
Without Tension
|
10.0D
|
||
|
Under Maximum Tension
|
20.0D
|
|||
|
Temperature range（℃）
|
Installation
|
-20~+60
|
||
|
Transport&Storage
|
-20~+60
|
|||
|
Operation
|
-20~+60
|
|||
| Fiber Mode | Single Mode |
|---|---|
| Fiber Count | Simplex |
| Cable Type | Drop Cable |
